Takeuchi - TB210R Excavators

The TB210R has many new and exciting features that will enhance performance, comfort, and serviceability. A new Kubota D722-E4B three cylinder engine powers the TB210R and delivers nearly 22% more power than its predecessor the TB108. Key upgrades include pilot operated joystick controls, a control pattern change valve for ISO/SAE controls enabling the operator to choose a preferred operational pattern, selector valve for one-way and two-way auxiliary hydraulic flow, and a pilot accumulator that allows residual pressure in the auxiliary hydraulic lines to be released, and it makes it possible for the work equipment to be safely lowered to the ground with the engine off. One can quickly see the changes to the exterior as the TB210R is a minimal tail-swing machine with a foldable ROPS/TOPS, retractable undercarriage and blade, and a boom cylinder that has been repositioned to the top of the boom for greater visibility. If your application requires a machine that will excel in the most confined applications then look no further than the Takeuchi TB210R compact excavator.


Key Specifications
Operating Weight Canopy 2,370 lbs (1,075 kg)
Maximum Digging Depth 5 ft 9.1 in (1,755 mm)
Maximum Bucket Digging Force 2,518 lbs (1,142 kg)
Horsepower 11.7 hp (8.7 kW)
