Yanmar Construction Equipment - V8 Wheel Loaders

Our all new articulated wheel loaders pack YANMAR's legendary power and versatility in a compact, nimble package, allowing you to easily navigate tighter spaces. Powered by powerful, yet fuel-efficient, Tier 4 Final diesel engines, they lift and move heavy loads with ease. Instantly switch from Fully Automatic Mode to Fixed Speed Mode for maximum torque in tough conditions. Save time with YANMAR's innovative Auto-Leveler that quickly returns the bucket to the digging position in a single motion. A comfortable, spacious cab and an oscillating rear axle keep you from taking a pounding on slopes and bumps, and you'll stay sharp and focused all day long.


Key Specifications
Operating weight (SAE J 1197) 10,802 lbs (4,900 kg)
Tipping load, straight at full reach (ISO 14397-1) 8,311 lbs (3,770 kg)
Tipping load, articulated at full reach (ISO 14397-1) 7,341 lbs (3,330 kg)
Engine model Deutz, TCD 2.9 L4
Displacement 177 in3 (2,900 cm3 )
Net power rating at 2,200 rpm (SAE J 1349) 60 hp (45 kW)
Max. torque 177 lb ft (240 Nm) @ 1,600 rpm
