Volvo Construction Equipment

A35D

Articulated Hauler


A35D

As a preparation for coming emissions regulations the D12D engine was introduced for A35D and A40D. The D12D engine met US (EPA) step 2, California (CARB) step 2 and Europe (EU) step 2 emission standards. Basic specifications such as power and torque are the same for D12C and D12D engines. The production started in November 2004.

In order to meet the Tier 3 / Stage IIIA legislative demands concerning exhaust emissions, a new version of the Volvo D12 engine was developed for A35D and A40D.

V-ACT (Volvo Advanced Combustions Technology) was implemented on the D12D engines for the US market only as from April 2005 and the EU market started from January 2006. The Tier 2/Step II compliant D12D engine continued to be available for affected markets.

VIEW FULL PROFILE

Specs

Key Specifications
Engine Model Volvo D12D AC E3
Load capacity SAE struck 15,2 m3
Load capacity SAE 2:1 heap 20,0 m3
Payload 32,5 t
Net weight 28,3 t
