Rockster North America Inc. - RDS514/RTS514 Mobile Screens

The track-mounted two-deck screening plant RDS514 combines efficiency with robust but compact design, short setup times, superior screening results and reduced fuel consumption. The RDS514 is used for screening of sand, gravel, construction and demolition waste. Like all Rockster screening plants, the RDS514 is easy to handle and can be single operated. With the same technical design as the RDS514, the mobile screen RTS514 has a third screening deck for an additional final fraction and very well defined grain.

Specs

Key Specifications
Screen Surface Top deck: Length: 4,35 m / 14.3 ft Width: 1,50 m / 4.9 ft Second deck: Length: 4,35 m / 14.3 ft Width: 1,50 m / 4.9 ft Bottom deck: Lenght: 3,60 m / 11.8 ft Width: 1,50 m / 4.9 ft
Feedhopper 8 m³
Drive unit CAT 4.4 engine - 75 kW / 100 hp - Stage 3a or 3b
Discharge heights Fines (teil) belt: 4,30 m / 14.1 ft Mids belt: 4,40 m / 14.4 ft Oversize belt: 4,40 m / 14.4 ft Auxiliary belt: 4,80 m / 15.8 ft
Weight 26,5 t / 58,400 lbs
